Full View 24 Pin 64.46*117.40 480*854 K495I40100 RGB IPS TFT Display Screen
General Specifications:
| Item | Standard Value |
| Display format | 480 * RGB * 854 |
| Outline Dimension | 65.30(W)* 119.30(H) * 2.1+-0.1(T) |
| LCD Size | 64.46*117.40 |
| Display area | 61.56*109.53 |
| Pixel size | 0.12825*0.12825 |
| display mode | Normal Black |
| Pixel component | R.G.B Stripe |
| Arrangement | RGB |
| LCD MODEL | a-Si TFT |
| DRIVE IC | ST7701S |
| FPC | --- |
Pin Assignments
| PIN | Pin Definition definition definition | Function Declaration |
| 1 | LEDK | Cathode of backlight |
| 2 | LEDA | Anode of backlight |
| 3 | GND | Ground |
| 4 | VCC | Connect to an external power supply of 2.5 ~ 3.3V. |
| 5-12 | R7-R0 | Data bus |
| 13-20 | G7-G0 | Data bus |
| 21-28 | B7-B0 | Data bus |
| 29 | DGND | Ground |
| 30 | DCLK | DPI: Dot clock signal Fix to DGND level when not in use. |
| 31 | DISP | NC |
| 32 | HSNC | DPI: Line synchronizing signal Fix to DGND level when not in use. |
| 33 | VHSYNC | DPI: Frame synchronizing signal Fix to DGND level when not in use. |
| 34 | DE | DPI: A data ENABLE input signal Fix to DGND level when not in use. |
| 35 | NC | NC |
| 36 | GND | Ground |
| 37 | RESET | Reset signal, keep Low for more than 10ms after power-on. |
| 38 | SDI | SDA: Serial data input/output bidirectional pin for SPI Interface. Fix to DGND level when not in use |
| 39 | SCL | SCL: Serial clock input for SPI |
| 40 | CS | Chip select input signal Low: the chip is selected and accessible High: the chip is not selected and not accessible |
BIBUKE TFT LCD Module Series:
1. Our standard TFT LCD Module size:
1.44'', 1.77", 2.0", 2.4", 2.8", 3.2", 3.5",
4"(3.97"), 4.3", 5", 7", 8", 9'', 10.1".
2. Developed 4.0''(3.97'') LCD module with IPS glass.
3. Developed 2.4'' to 7.0'' TFT LCD with ZIF FPC connection.
4. Standard CTP for 3.2'', 3.5'', 4.3", 5.0", 7'', 8'', 10.1''.
5. High transmittance RTP for 4.3" and 7".
6. Can make customized CTP.
Packaging & Shipping:
Packaging: Carton boxess, Cupboard , EPE, Blister Tray, About the package way, it is up to the size of products,
according to customer request and demand. Different countries have not same requirement..
Shipping: Express way as DHL,Fedex,EMS,UPS,air shipping,sea shipping,Any shipping method you prefer.
Payment Method:
FAQ:
1. I want the LCD display 8 digits and the outline size is 65x30x2.8mm………?
Answer: No problem. Firstly, please kindly send us your specification/ drawing paper
If you have not the specification, you can also provide your samples; we will recommend the suitable one
if it is standard products. Or we can customize for you based on your own requirement.
2.This LCD is just what we want, but it is big size, do you have any smaller size? And the display content need to be changed a little.
Answer: For the segment type LCD module, if you need modify the outline size or display content,
a new LCD glass module is need. We have to open new tooling for you.
3. This LCD display is HTN type, but I want STN type,can you make?
Answer: That’s all right . we can change for you as per you request.
4. I want customize a new LCD module. Can you do?
Answer: Yes, we can. Please send your drawing paper. If you have not, please advise me the outline size
of the LCD display, display information( Glass thickness, Polarizer, Display Type, Connector mode,
Storage Temp. Operating Temp. Supply Voltage, Viewing direction, drive condition), we can customize for you.
5. What is leading time for tooling?
Answer: General speaking, it will cost 15 to 25 days after drawing paper confirmation and tooling charge payment,
we can report you the exact time when you confirm the drawing paper.
6. Can you send us samples for checking?
Answer: Yes,. Samples order is available.
7. What is the Leading Time?
Answer: If we have stock for the standard ones, the leading time is one day after payment. If it is the mass production for
special ones, the leading time is about 15-30 days. suppose we can finish earlier, we will report the information in advanced.
Our Services:
1. Free repair within one year after the shipment of products from us.
2. Replacement within 30 days after the shipment of products from us due to products' problems.
3. We can print your logo and stick your model No.on the cameras.
4. We have long cooperation with many shipping companies and our export volume is large. The shipping companies
can offer us good discounts.
5. Professional technician supports. We have a good after-sales service team. They can solve your problems in time.
6.All goods will be inspected and tested by our engineers and QC/QA before packing and shipment.
7.Customers satisfactory is most important to us.If you have any problem or questions regarding our transaction.Please contact us by Email or online. It will be responded within 24 hours.
8.Products pictures only for your reference. please kindly refer to the specification. we can provide the products basic on the specification. or you can offer your own specification or drawing , we can customize all kinds of LCD displays for you. thanks for your kind support always.
Product application
Household appliances-refrigerators: air conditioners, fans, hot and cold air heaters, water heaters, electric blankets, heaters, air purifiers, washing machines, clothes dryers, vacuum cleaners, lampblack cleaners, microwave ovens, cookers, electric ovens, rice cookers, water drinkers, tea sets, etc.;
Communication :equipment-telephone, interphone, fax machine, wireless wifi, etc.
Automotive: electronics-on-board entertainment system, automobile fault detector, CarLog, vehicle navigator, car audio, reverse radar, reverse mirror, camera, anti-theft device, etc.
Instruments :water meters, electric meters, multimeter, electronic scales, pressure meters, temperature meters, flow meters, display instruments, electrical instruments, space instruments, measuring instruments, analytical instruments, electrochemical instruments, optical instruments, etc.;
Fitness: equipment-treadmill, waist machine, fitness bike, training device, pedometer, code table, beauty instrument, fat square measuring instrument, fitness instrument, electronic sphygmomanometer, weighing scale, etc.
Financial :tax control-tax control cash machine, poss machine, usb-key cheque printer, banknote counting machine, tax control invoice machine, etc.
Consumer electronics:mp3,mp4,dvd, electronic dictionary, click reader, early teaching machine, learning machine, electronic organ, electronic clock, chronograph, calculator, etc.
high resolution, high definition, high brightness, cost-effective, energy conservation, high temperature, low temperature, Wide Temperature Range, Positive, Negative
